Operator Environment
The Spirit Delta cab gives the operator an efficient and safe place to work from. The cab design is the end result of a major study of operators' working conditions. The most important goal is to provide optimum visibility with no forward corner posts and big glass areas unobstructed so as to keep the field of vision clear. The ergonomically designed instrument panel is really comfortable and gently rounded. This specific area has also been designed with an unobstructed clear view of all important information, in order to keep the operator functioning as effectively as she or he could.
Due to the insulated mounting to the chassis, vibration levels and overall noise levels are kept low. The hydraulic controls and the operators' seat are all individually adjustable in order to maintain an optimum working position. Furthermore, the steering wheel and related panel is adjustable for maximum comfort. There are 2 multi-functioned ergonomically positioned and simple to operate levers that are provided for the window washers, horn, windscreen wipers and gear changing.
A ventilation/heating unit guarantees a comfortable cab temperature for the operator. The incoming air is replaced by an air filter. This is easily replaceable and the unit slides out afterwards to make serviceability an easy option. The machinery has a robust 3-speed fan for recirculation, defrosting, heating and cooling. As an additional option, air conditioning can be fitted.
Instrumentation
In the Spirit Delta, the instrument panel has logically grouped units which are all accessible. Basic instrumentation includes: low engine and gearbox lubrication oil pressure, warning lamps, high coolant temperature, low brake pressure, applied parking brake and high gearbox oil temperature. In addition, gauges display values for engine coolant, gearbox oil pressure, operating time and fuel quantity.
The ECS or also called Electronic Control System monitoring is one of the important options on the 8 to 10 tonne trucks. These units make it easier to supervise the machine. All of the monitoring functions are handled by the ECS or Electronic Control System and incorporated by this system. The single warning lamp and the full text display show any faults which take place and their current values.
